CS90, the weapon system with firing capability from very small confined spaces

CS90

90 mm caliber Weapon System for infantry composed of a variety munitions (anti-tank, dual purpose and anti-bunker) integrated in a disposable launching tube, which can be fired from very small confined spaces.

The system includes a new 2X folding optical sight and a firing mechanism, both integral parts of the disposable launching tube. Two night vision devices are available, the VN38-C (image intensifier tube) and the VN-IR (thermal camera), that do not require bore sighting and can be attached and removed in the battlefield within seconds. VN38-C includes interchangeable optics to be used also for surveillance purposes with 3,3X magnification.

Available training systems: subcaliber trainer TR90-BT and simulated trainer SAARA (M2)

CS90

coloca el cursor encima para reproducir el vídeo

Capabilities

  • Lightest 90 mm caliber weapon system in the world to be fired from enclosure with a weight of 6,5 kg (closest competitor 7,5 kg)
  • Unique with remote firing capability
  • Recoilless <4 J
  • Great Accuracy. It is fired from the shoulder with an effective range of 350 m for point targets and 700 m for area targets
  • To be fired from very small confined spaces
  • 2X folding and optical sight integrated in the disposable launching tube
  • Mechanical interface for fast insertion of nitght vision devices
  • Extremely comfortable and easy to use

Technical Specifications

Munitions
CS90-AT
CS90-DP
CS90-BK
Anti-tank Dual purpose
Anti-armour
+ fragmentation
Anti-bunker
Weight (Transport Configuration) 6,7 kg 6,8 kg 7,2 kg
Effective Range 350 m (point target) 350 m (point target)
700 m (area target)
350 m (point target)
Penetration 500 mm
(armour steel)
>1.000 mm
(concrete)
220 mm
(armour steel)
>500 mm
(concrete)
120 mm
(armour steel)
300 mm
(concrete, for 2nd
warhead through)
Fragments >1.000 >2.500 (inside bunker)

Ammunition Capabilities

Anti-Armour
Anti-Bunker
Fragmentation
Blast
CS90-AT
100%
100%
50%
50%
50%
50%
75%
75%
CS90-DP
75%
75%
50%
50%
100%
100%
50%
50%
CS90-BK
50%
50%
100%
100%
50%
50%
50%
50%
